BIM, Taking your drawings to the next level The future of CAD drawings and their involvement in the construction process is changing! 2D drawings will always have a valued and useful position in the construction process, but anyone who is serious in providing quality information to their clients will be looking at designs created using Building Information Modelling (BIM) techniques.
BIM
The traditional building design was largely reliant upon two-dimensional drawings (plans, elevations, sections, etc.). Building information modeling extends this beyond 3-D, augmenting the three primary spatial dimensions (width, height and depth - X, Y and Z) with time as the fourth dimension and cost as the fifth. BIM, therefore, covers more than just geometry. It also covers spatial relationships, light analysis, geographic information, and quantities and properties of building components (for example manufacturers' details).
We are experts in generating structure BIM models using Revit platform. With our expert Revit technicians and structure detailer’s we are competent enough to develop models for Steel Structures, Wood Structures and Concrete Structures. Also, we are experts in creating families for structure detailing like joists, Anchor bolts, trusses etc.
